EMBER Cooktop

Installation

On receipt, record the SKU, serial number, voltage, fuel and controller revision, and photograph the nameplate. Check the heater, harness, controller, pump, pipes, seals and fasteners actually supplied. Prepare maintenance access, protected routing, a suitable electrical supply and combustion exhaust outside the occupied space.

Check stability, clearances and whether the variant is for indoor or outdoor use. Distinguish cooking-only, combined heating and portable cooktops; provide the specified intake and exhaust.

Use the mounting points and clearances specified for the delivered unit. Mount horizontally within 5° and keep access to the fuel, wiring and slide mechanism.

Use outdoors while stationary. Confirm the fuel circuit, wiring and controller revision with a qualified installer. Do not mix the dimensions or mounting instructions for a recessed/lifting stove with this pull-out model.

Commissioning checks

Check mounts, connections, protective devices and seals before starting. Bleed or prime only as instructed in the manual. Measure voltage at the appliance during startup; check stable operation, temperatures and unusual smoke or leaks. Test controlled shutdown and completion of cooling, recording conditions, measurements and serial number.

Operation

Pull out and lock both slide stages before starting. Keep the cooking surface clear and do not cover an operating appliance.

Follow the supplied controller instructions. Complete shutdown and cooling before retracting, moving or refuelling.

Maintenance

Inspect fuel-line leaks, wiring connections, corrosion and slide locking. Have installation and service work performed by qualified personnel.

Troubleshooting & support

Record the exact error code, a screen photograph, voltage at rest and startup, symptoms and circumstances. Check supply/connectors, fuel, intake and exhaust; on coolant systems, also check filling, bleeding and circulation. Use the installed controller’s code table; do not interchange OLED, LCD and AT1192 codes. Stop for leaks, odours or overheating and obtain professional diagnosis before replacing electronics.

Before you buy

• Required use and output
• Voltage and fuel
• Available installation space
• Combustion intake and exhaust
• Compatible controller and required installation components
• Exact packing list

Select for actual use, heat losses, climate and installation architecture. Nominal output alone does not establish compatibility or autonomy.
